Redmi 13c 5G (air) Flash File , Fix Dead Boot Hang on logo

Flashing a Xiaomi Redmi 13C with SP Flash Tool involves a few critical steps. It’s important to follow these steps carefully, as incorrect flashing can brick your device. Before you begin, make sure you’ve backed up all your data and understand the risks involved. Here’s a step-by-step guide:

Prerequisites

1. SP Flash Tool – Download the latest version from the official website.
2. Firmware/ROM – Download the correct firmware for the Redmi 13C. Ensure it’s compatible with your device’s model and region.
3. MediaTek USB Drivers – Install the necessary drivers on your computer for the SP Flash Tool to recognize your device.
4. USB Cable – Use the original or a high-quality USB cable to connect your device.

Steps to Flash Redmi 13C with SP Flash Tool

1. Install MediaTek USB Drivers:
   • Unzip and install the MediaTek USB drivers on your computer.
   • Restart your computer after installation to ensure the drivers are properly configured.
2. Extract the Firmware:
   • Extract the downloaded firmware to an easily accessible folder on your computer.
   • Inside the firmware folder, you should see files such as scatter.txt, which is needed for the SP Flash Tool.
3. Launch SP Flash Tool:
   • Open the SP Flash Tool as an administrator.
   • In SP Flash Tool, click the “Choose” button under the “Download-Agent” section. Navigate to the folder where SP Flash Tool is stored, and select the MTK_AllInOne_DA.bin file.
4. Load the Scatter File:
   • Click on “Choose” under the “Scatter-loading File” section.
   • Navigate to the extracted firmware folder and select the scatter.txt file. This will load all the firmware files into SP Flash Tool.
5. Select Flashing Mode:
   • Ensure “Download Only” is selected if you want to preserve your data. For a clean install, choose “Format All + Download” (this will erase all data).
6. Connect Your Device:
   • Power off your Redmi 13C.
   • Connect it to the computer using the USB cable.
   • SP Flash Tool should recognize the device and show a connection status.
7. Start Flashing:
   • Click the “Download” button in SP Flash Tool.
   • SP Flash Tool will begin flashing the firmware. This process may take a few minutes. Do not disconnect the device during this process.
8. Wait for Flash Completion:
   • Once flashing is complete, you’ll see a green checkmark in SP Flash Tool indicating success.
   • Disconnect your device and restart it.

Troubleshooting Tips

• SP Flash Tool Not Detecting Device: Reinstall drivers and try a different USB port or cable.
• Stuck on Boot Logo: Try wiping data/factory reset from Recovery Mode.

Important Notes

• Flashing may void your warranty.
• Use only the correct firmware for your specific model to prevent bricking.
• Make sure your device has enough battery (at least 50%) to prevent interruptions.

If you encounter issues, double-check each step, especially with driver installation and firmware compatibility.
